Holley
Holley EFI Fuel Pump Module - 255 LPH 1973-1987 GM C/K Series Truck
Holley EFI Fuel Pump Module - 255 LPH 1973-1987 GM C/K Series Truck
SKU:12-308
100 in stock
- Ships from Kentucky or Utah
- Add $300+ for $10 off of your order!
- Add $500+ for $20 off of your order!
Shipping Estimate
Shipping Estimate
Tracking: 1-2 days
Average Shipping: 2-3 days once tracking is available
Regular price
$391.95 USD
Regular price
$489.95 USD
Sale price
$391.95 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Holley EFI Fuel Pump Module - 255 LPH 1973-1987 GM C/K Series Truck
In-tank fuel pump module for 1973-1986 Jeep CJ Models with 15 Gallon Steel Tanks. Supports Up To 550 Horsepower.
Overview
This in-tank fuel pump module is a high-pressure unit that flows 255 liters per hour (LPH) and is capable of supporting electronic fuel injection (EFI) engines producing up to 550 horsepower. Built for Jeep CJ's featuring a 15 gallon steel tank. Featuring a pre-calibrated fuel-level sending unit designed to work with the factory fuel gauge for this application is included. This module also features a HydraMat filter which has a unique internal reservoir that keeps fuel available at the pick-up and also provides protection from contaminates. A fuel pressure is internally regulated to 58 psi eliminating the added expense and effort of purchasing and installing an external fuel pressure regulator - no separate return line is required because this module returns excess fuel right inside the tank! This 1973-1983 Jeep EFI Fuel Pump module was designed as a direct replacement for your factory pick-up and sending unit. There is no need to purchase a custom EFI fuel tank. You can even retain the factory fuel hard line - just connect the outlet of the pump module to the hard line on your vehicle with EFI-rated fuel hose and hose clamps available in the Earls Vapor Guard line. This Muscle Car EFI Module includes a 255 LPH fuel pump and a Holley HydraMat. HydraMat is an amazing patent-pending fuel reservoir system that reduces fuel starvation issues that might otherwise occur while cornering, accelerating, stopping, traversing inclines, and during low fuel conditions.
The pump is not compatible for use with PWM (Pulse-width Modulation)
Details:
Links
Instruction Sheet
View full details
In-tank fuel pump module for 1973-1986 Jeep CJ Models with 15 Gallon Steel Tanks. Supports Up To 550 Horsepower.
Overview
This in-tank fuel pump module is a high-pressure unit that flows 255 liters per hour (LPH) and is capable of supporting electronic fuel injection (EFI) engines producing up to 550 horsepower. Built for Jeep CJ's featuring a 15 gallon steel tank. Featuring a pre-calibrated fuel-level sending unit designed to work with the factory fuel gauge for this application is included. This module also features a HydraMat filter which has a unique internal reservoir that keeps fuel available at the pick-up and also provides protection from contaminates. A fuel pressure is internally regulated to 58 psi eliminating the added expense and effort of purchasing and installing an external fuel pressure regulator - no separate return line is required because this module returns excess fuel right inside the tank! This 1973-1983 Jeep EFI Fuel Pump module was designed as a direct replacement for your factory pick-up and sending unit. There is no need to purchase a custom EFI fuel tank. You can even retain the factory fuel hard line - just connect the outlet of the pump module to the hard line on your vehicle with EFI-rated fuel hose and hose clamps available in the Earls Vapor Guard line. This Muscle Car EFI Module includes a 255 LPH fuel pump and a Holley HydraMat. HydraMat is an amazing patent-pending fuel reservoir system that reduces fuel starvation issues that might otherwise occur while cornering, accelerating, stopping, traversing inclines, and during low fuel conditions.
The pump is not compatible for use with PWM (Pulse-width Modulation)
Details:
- Application: 1973-1987 Chevrolet / GMC C10 Series Truck
- Choose Your Part: Fuel Pump Module
- Free Flow LPH: 255
- Fuel Sending Unit Ohms: 0-90 Ohms
- Fuel Type: Gasoline
- Material: Steel
- Truck Bed Length: Long Bed
- Truck Bed Length: Short Bed
- Warranty: Limited 90 Day
Links
Instruction Sheet
