Holley

Holley EFI Crank Trigger System - SBC

Holley EFI Crank Trigger System - SBC

556-116

Low stock: 6 left

  • Ships from Kentucky or Utah
  • Add $300+ for $10 off of your order!
  • Add $500+ for $20 off of your order!

Shipping Estimate

Tracking: 1-2 days

Average Shipping: 2-3 days once tracking is available

$610.95 USD
$762.95 USD $610.95 USD
Sale Sold out
Shipping calculated at checkout.
Holley EFI Crank Trigger System - SBC

36-1 Tooth Crank Trigger System for Small Block Ford

Overview
Holley's EFI Crank Trigger Kit is engineered to provide an accurate crank speed & position signal to Holley EFI systems in the most-demanding, high horsepower, racing applications. Crank position is measured every 10 degrees as opposed to every 45 degrees for a standard 4-Magnet, MSD "style" Crank trigger. It is designed for use on SBF applications using a standard ATI or Fluidamper "style" balancer up to 7-1/4" in diameter.

Will not work on balancers which do not have a center-hub extrusion (i.e.: Innovators West, etc.).

Features:
  • 8??? diameter, 1/4??? thick, billet steel, 36-1 tooth, crank wheel with Black Zinc Oxide finish for superior corrosion resistance & striking good looks.
  • Crank wheel centers off of the balancer??????s hub, eliminating the need for a centering ring
  • All billet, 6061-T6 aluminum sensor mounting brackets with bright-dipped??? black anodized finish & Laser etched Holley EFI logo
  • Custom 3-wire, ferrous-target, Hall-effect sensor with M12X1mm threads for finer gap adjustment
  • All Grade 8 & Mil. Spec mounting hardware


Details:
  • Color: Black
  • Diameter: 8 in.
  • Diameter: 8"
  • Finish: Black Zinc Oxide
  • Make: Chevrolet
  • Sensor Dimensions: 12mm x 50mm
  • Sensor Type: Hall Effect
  • Trigger Type: 36-1
  • Wheel Width: 1/4"
